For more product information, technical data and product manuals, visit our website www.leopumps-europe.com. 1 a Water is Life Group company PRODUCT BROCHURE INTELLIGENT FLOW FOR GOOD WWW.LEOPUMPS-EUROPE.COM
2 SELF PRIMING JETPUMPS cast iron - multistage cast iron - stainless steel - multistage silent JET PUMP CAST IRON (single phase) • Jetpump with SS-AISI/304 impeller • Power: 0,3 kW/230V - 1,5 kW/230V • Max. volume: 2,1 m3/h - 8,4 m3/h • Max. height: 35 m - 65 m • In-/outlet connection: 1” (1.1/4”) - 1” AJm30 - AJm45 AJm60 - AJm-75 AJm90 - AJm110 AJm150 JET PUMP STAINLESS STEEL • Silent 0,3 kW/230V - 0,9 kW/230V • Max. volume: 2,4 m3/h - 3,6 m3/h • Max. height: 30 m til 48 m • In- and outlet connection: 1” - 1” AJm30S - AJm45S AJm60S - AJm75S AJm90S STAINLESS STEEL GARDEN JET PUMP • Garden jetpump with SS-AISI/304 impeller • Power: 0,9 kW/230V • Max. volume: 3,6 m3/h • Max. height: 43 m • In- and outlet connection: 1” - 1” • With on/off switch 1.5 m cable XKJ904S JET PUMP CAST IRON (three phase) • Jetpump with SS-AISI/304 impeller • Power: 1,1 kW/400V - 2,2 kW/400V • Max. volume: 4,8 m3/h - 8,4 m3/h • Max. height: 55 m til 60 m AJ110 - AJ220 AJ150 The LEO self-priming pumps can be used to transfer clean water or other liquids similar to water. Suitable for lifting water from the well, sprinkling irrigation in garden, pressure boosting of running water, supporting equipment, etc... Domestic series available as complete boosterset with hydrophore tank or pumpcontroller. PUMP MOTOR Cast iron pump body C&U bearing or SS-AISI/304 pump body Motor with copper winding Special anti-rust treatement Built-in thermal protector Stainless steel and thermoplastic impellers for single phase motor AISI 304 shaft Insulation class F Max. liquid temperature +40°C Protection class IPX4 Max. suction +9 m Max. ambient temperature +40°C
For more product information, technical data and product manuals, visit our website www.leopumps-europe.com. 3 SELF PRIMING JETPUMPS cast iron - multistage cast iron - stainless steel - multistage silent MULTISTAGE CAST IRON PUMPS • Silent pump with thermoplastic impellers • Power: 0,6 kW -0,75 kW/230V • Max. volume: 4,2 m3/h - 5,4 m3/h • Max. height: 35 m - 46,5 m • In- and outlet connection: 1” - 1” 3ACm60 - 4ACm75 MULTISTAGE STAINLESS STEEL • Silent pump with 4 or 5 thermoplastic impellers • Power: 0,75 kW/230V - 0,9 kW/230V • Max. volume: 5,4 m3/h - 6 m3/h • Max. height: 45 m -55 m • In- and outlet connection: 1” - 1” 4ACSm100S - 5ACSm100S MULTISTAGE STAINLESS STEEL • Silent pump with 4 thermoplastic impellers • 0,6 kW/230V - 0,9 kW/230V Max. volume: 4,8 m³/h - 5 m3/h • Max. height: 34 m -56,5 m • In- and outlet connection: 1” - 1” 3XCm 120C - 4XCm 120C 5XCm 120C MULTISTAGE SILENT • Silent pump with body in ABS - SSAISI/304 impeller • Power: 0,75 kW/230V - 0,9 kW/230V • Max. volume: 5,4 m3/h • Max. height: 35 m - 60 m • In- and outlet connection: 1” - 1” 3XCM/129PS(E) 4XCM/129PS(E) 5XCM/129PS(E)
4 SINGLE IMPELLER CENTRIFUGAL (medium flow) • Power: 0,6 kW/230V - 7,5 kW/400V • Max. volume: 54 m3/h • Max. height: 56,5 m ACm25 - AC750C4 DOUBLE IMPELLER • Power: 0,75 kW/230V - 4,1 kW/400V • Max. volume: 4,8 m3/h - 15 m3/h • Max. height: 45 m - 82 m 2ACm75 - 2AC400H SINGLE IMPELLER • Power: 0,37 kW/230V/380V - 1,5 kW/230V/400V • Max. volume: 4,8 m3/h - 9,6 m3/h • Max. height: 20,9 m - 30,2 m AMS(m)120/1.1 AMS(m)210/1.5 OPEN IMPELLER • Power: 0,37 kW/230V/380V - 3 kW/230V/400V • Max. volume: 6 m3/h - 66 m3/h • Max. height: 11,6 m - 7,5 m ABK50(D) - ABK400(D) CAST IRON OPEN IMPELLER • Power: 1,1 kW/230V - 1,5 kW/230V • Max. volume XHSm 1500: 16,2 m3/h - XHSm 2000: 19,8 m3/h • Max. height : XHSm 1500: 15 m - XHSm 2000: 20,5 m • In- and outlet connection: 2” - 2” XHSm 1500 - XHSm 2000 SINGLE IMPELLER CENTRIFUGAL (high flow) • Power: 0,6 kW/230V - 7,5 kW/400V • Max. volume: 11,4 m3/h - 71 m3/h • Max. height: 17,5 m - 52,5 m ACm60B2 PERIPHERAL PUMP • Power: 0,25 kW/230V - 0,75 kW/230V • Max. volume: 2,1 m3/h - 3 m3/h • Max. height: 40 m - 75 m • Brass star-impeller APm37 - APm75 Centrifugal pumps for industrial use and urban water supply, pressure boosting for high buildings and fire fighting, garden irrigation, long-distance water transfer, heating ventilation and air controlling, circulation and pressure boosting for cold and hot water and supporting equipment etc. PUMP MOTOR Cast iron & RSV pump body's C&U bearing Special anti-rust treatement Motor with copper winding AISI 304 shaft Built-in thermal protector for Max. liquid temperature +40°C single phase motor Max. suction + 8 m Insulation class F Protection class IPX4 Max. ambient temperature +40°C (three phase, power ≥ 0,75 kW) CENTRIFUGAL PUMPS star-impeller peripherial- single impeller - double impeller - cast iron
For more product information, technical data and product manuals, visit our website www.leopumps-europe.com. 5 (monoblock, until 7,5 kW) (monoblock, until 7,5 kW) (close coupled, from 9,2 kW) (close coupled, from 9,2 kW) NORMALIZED PUMPS centrifugal ss-aisi/304 - centrifugal cast iron Normalized centrifugal pumps are mainly used for circulation, cooling systems, irrigation and transfer of clean, chemically light-aggressive water and other liquids. PUMP MOTOR Available in cast iron or SS-AISI/304 Copper or aluminium winding Impeller AISI/304 - HT200 Built-in overload motor protector AISI 304 shaft Insulation class F Max. liquid temperature +85°C Protection class IP54 Max. operating pressure 12 bar Performance in compliance CEI 2-3 (IEC 34.1) DN connections = EN 733 (DIN 24255) Sic/Sic mechanical seal (DIN 24960) CENTRIFUGAL SS-AISI/304 • Power: 1,1 kW/230V - 22 kW/400V • Max. volume: 6 m3/h - 132 m3/h • Max. height: 58 m • Monoblock up to 7,5 kW • Close coupled from 9,2 up to 22 kW (flanged B5 motor, optional Ex) XZS50 - XZS65 XZS80 - XZS100 CENTRIFUGAL CAST IRON • Power: 0,75 kW/230V - 37,5 kW/400V • Max. volume: 18 m3/h - 210 m3/h • Max. height: 17,5 m - 95 m • Monoblock up to 7,5 kW • Close coupled from 9,2 kW up to 37 kW (flanged B5 motor, optional Ex) XST32 - XST40 - XST50 XST65 - XST80
6 SUBMERSIBLE PUMPS drainage, sewage and dewatering Can be used to transfer clean or slightly dirty water or other liquids similar to water. Suitable to be immersed in water for lifting water from a cellar or a pool, and draining water from the basement. Can be used to transfer heavy dirty water, sewage or other liquids similar to water. Suitable to be immersed in water for lifting gray water, waste water, sewage water and heavy polluted drainage water from construction sites. PUMP MOTOR High engineered plastic/SS 304 body Motor with aluminium winding Upper and side-outlet Built-in thermal protector Float switch ensures automatic Insulation class F cut-in and cut-out Protection class IPX68 Max. liquid temperature +35°C Max. immersion depth 7 - 12 m Max. diameter of particle 1 - 15/35 mm PUMP MOTOR Pump body HT200y Motor with copper winding Upper and side-outlet Built-in thermal protector Float switch ensures automatic Insulation class F cut-in and cut-out Protection class IPX68 Max. liquid temperature +40°C Max. diameter of particle 8,5 mm - 19,5 mm PLASTIC DRAINAGE AND SEWAGE PUMPS • Power: 0,25 kW/230V - 1,0 kW/230V • Max. volume: 0,9 m3/h - 12,6 m3/h • Max. height: 5,8 m - 11,6 m • Cable with plug: 10 meter. AKS-751PSW SEWAGE CUTTER PUMPS • Power: 0,75 kW/230V • Max. volume: 15 m3/h • Max. height: 13 m • Cable with plug: 10 meter. LSWm100CA DEWATERINGS PUMPS • Power: 2,2 kW/230V - 5,5 kW/230V • Max. volume: 3 m3/h - 105 m3/h • Max. height: 15 m - 10,5 m KBZ 21.5 - KBZ 45.5 KBZ 47.5 - KBZ 615
For more product information, technical data and product manuals, visit our website www.leopumps-europe.com. 7 HIGH-PRESSURE AUTOMATIC • Power: 0,9 kW/230V - 1,1 kW/230V • Max. volume: 0,9 m3/h - 6 m3/h • Max. height: 35 m - 45 m • Built-in pumpswitch • Standard with 15 mtr. cable (HO7RNF) LKS-900S (with strainer) LKS-902SE / LKS-1102SE (with strainer) LKS-902SE-1 / LKS-1102SE-1 (1” side-inlet) HIGH-PRESSURE RESERVOIR • Power 5DW2: 0,55 kW - 1,1 kW • 5DW2 max. flow: 4,5 m3/h max press. 8,7 bar • Max. volume 5DW2: 1 m3/h - 4,5 m3/h • Max. height 5DW2: 33 m - 87,5 m 5DW2 Model Power DELIVERY n□2850 rpm 1- 3kW Q (m³/h) 0 1 1.5 2 2.5 3 3.5 4 4.5 230V 230V 400V Q (l/min) 0 17 25334250586775 5DWm2/3-0.55P 0.55 H (m) 33 31 29.5 27.5 25 22 19 16 12 5DWm2/5-0.75P 5DW2/5-0.75P 0.75 53 49.5 47 44 40 35 30 25 19 5DWm2/6-0.9P 0.9 65 61 58 54 49 43 37 30.5 23 5DW4 Q (m³/h) 0 0.6 1.2 1.8 2.4 3.0 3.6 4.2 4.8 5.4 6.0 MODEL kW Q (l/min) 0 10 20 30 40 50 60 70 80 90 100 5DWm4/4-0.75P 0.75 H (m) 51 50 49 47 44 41 36 331 25 20 14 5DWm4/5-0.92P 0.92 64 62 61 59 55 51 45 39 31 25 18 5DWm4/6-1.1p 1.1 77 74 73 71 66 61 54 46 37 30 21 5DWm4/7-1.3P 1.3 89 87 85 82 77 71 63 54 44 35 25 BOREHOLE 2,5” - 3”- 4” • Power: 0,37 kW/230V - 2,2 kW/230V • Max. volume 3”: 0,3 m3/h - 3,6 m3/h • Max. volume 4”: 0,6 m3/h - 14 m3/h • Max. height: 32 m - 148 m • Cable standard 30 m - HO7RN 2.5XRm - 3XRm - 4XRm Can be used for water supply from wells or reservoirs. Most suitable for domestic use, for rainwater harvesting applications in garden use and irrigation. Compact easy to use submersible pump with dry-running protection and built-in check valve. Motor with thermal protector. The SE1 types give the possibility for connecting a floating suctionhose, specialy for rainwater applications. Can be used for water supply from wells or reservoirs. Most suitable for domestic use, for rainwater harvesting applications in garden use and irrigation. MOTOR AND PUMP Single -phase 230V - 240V/50Hz Pumps are designed according to the latest European EEI norms Curve tolerance according to ISO 9906 Insulation class: F Protection class: IP68 MOTOR AND PUMP Single -phase 230V - 240V/50Hz Pumps are designed according to the latest European EEI norms Curve tolerance according to ISO 9906 Insulation class: F Protection class: IP68 Comes with plastic impeller Can be used for water supply from wells or reservoirs. Can be used for domestic use, for civil and industrial applications, for garden use and irrigation. MOTOR AND PUMP Rewindable motor screen motor Single -phase 230V - 240V/50Hz Three -phase 380V - 415V/50Hz Pumps are designed according to the latest European EEI norms Curve tolerance according to ISO 9906 RESERVOIR PUMPS high pressure submersible pumps BOREHOLES PUMPS borehole pumps - solar borehole AUTO ON/OFF
8 BOOSTER PUMPS vertical multistage monoblock - vertical multistage coupled BOOSTERS stainless steel horizontal multistage The LEO EVP monoblock vertical pumps are designed for semi-profesional boostersystems. Impellers in high strength thermoplastic. Suitable for water supply of high-rise buildings, filtration and transfer at waterworks, pressure boosting in main pipe. Washing and cleaning systems, boiler feeding, water circulation, watertreatment systems. Ultra-filtration, reverseosmosis and distillation systems. Agricultural irrigation, sprinkler systems and fire fighting. This innovative variable speed-pump with PM motor (permanent magnetic), is a energysaving technology who adjust performance by automatically reduce the speed to the according water demand, providing constant pressure to all taps. The watercooled motor makes the soundlevel lower than 47 dB(A) in standard use. The MAC550 is the newest compact all-in-one solution. DISCONNECTION SET It is applicable to household water supply, garden watering, fish farming and poultry raising, indus- trial and mining, high-rise buildings. Most countries don’t allow boostering directly on the main watersupply. LEO Europe can offer certified disconnection sets from 10 until 1000 lt. The LEO LVR (DIN-GG20-AISI/304) and the LEO LVS (SS-AISI/316) with drinkwater certification. Pumps are designed for water supply, high-rise buil- dings, filtration and transfer at wa-terworks, pressure boosting in main supply. Washing and cleaning systems, boiler feeding, water circulation, watertreatment systems. Ultra-filtration, reverseosmosis and distillation systems. Agricultural, sprinkler irrigation, food and beverage industry, fire fighting systems. Motor with standard B5 flange. PUMP MOTOR Stainless steel AISI/304 wetted parts IE 3 motor (IE 2 motor optional) Impellers in thermoplastic Totally enclosed and fan cooled Insulation class F - Protection class IP55 Standard voltage 50 Hz, 1 x 220V/3 x 400V PUMP MOTOR Stainless steel AISI/304-316 wetted parts IE 3 motor (IE 2 motor optional) Impellers in stainless steel Totally enclosed and fan cooled Insulation class F - Protection class IP55 Standard voltage 50 Hz, 1 x 220V/3 x 400V EVP MULTISTAGE MONOBLOCK • Material in SS-AISI/304 - DIN GG-20 • Power: 0,37 kW/230V - 7,5 kW/400V • Max. volume: 1,2 m3/h - 16 m3/h • Max. height: 12 m - 150 m • In and outlet connection: DN-25 (3/4”) til DN-38 (1.1/2”) • Max. liquid temperature: 60°C EVP2 - EVP10 LVR/LVS MULTISTAGE COUPLED • SS-AISI/316 or DIN GG-20 (LVR) • Cartridge seal • Power: 0,37 kW/230V - 110 kW/400V • Max. volume: 4,2 m3/h - 240 m3/h • Max. height: 12 m - 325 m • In and outlet connection: DN-32 til DN-200 • Max. liquid temperature: 120°C LVR-1 - LVR-200 LVS-3 - LVS-200 BOOSTERSET • Power: 0,55 kW/230V/50-60 Hz • Max. volume: 4,8 m3/h • Max. height: 42 m • Max. speed: 5200 RPM • Connections: in- and outlet 1” MAC 550
For more product information, technical data and product manuals, visit our website www.leopumps-europe.com. 9 PUMP MOTOR Plastic pump body Copper or aluminium winding ABS impeller Built-in thermal protector for AISI 304 shaft single phase motor Max. liquid temperature +35°C Insulation class F - Protection class IPX5 Max. suction +3,5 m SELF PRIMING PUMPS swimming pool - pool sandfilterset Self priming swimming pool pumps are used for water circulation in a small and medium-sized swimming pools. Slightly dirty water with solids in suspension can be perfectly filtered. • Type XKP250/450 • In- outlet: 1.1/2” - 40 mm • Type XKP554/1604 • In- outlet: 2” - 50 mm SWIMMING POOL PUMPS • Power: 0,25 kW/230V - 2,2 kW/230V • Max. volume: 7 m3/h - 30 m3/h • Max. height: 6,9 m - 17,8 m XKP250 - XKP450 XKP554 - XKP1604 SANDFILTER PUMPSET • Power: 0,6 kW/230V - 2,2 kW/230V • Max. volume: 8 m3/h - 24 m3/h • Max. height: 9,7 m - 17,8 m H2Q-QCC310 - H2Q-QCC600 It is applicable to household water supply, equipment support, pipeline pressurization, garden watering, vegetable greenhouse watering, fish farming and poultry raising, industrial and mining, water supply and drainage of enterprises and high-rise buildings, central air conitioner and centralized heating circulation systems, etc. It is applicable to household water supply, equipment support, pipeline pressurization, garden watering, vegetable greenhouse watering, fish farming and poultry raising, industrial and mining, water supply and drainage of enterprises and high-rise buildings, central air conitioner and centralized heating circulation systems, etc. PUMP MOTOR AISI/304 shaft and impellers Motor with copper winding Max. liquid temperature 85°C Built-in thermal protector for single phase motor Max. inlet pressure 10 bar Insulation class F Max. operation pressure 10 bar Protection class IP55 Liquid pH valvue 4 - 10 Max. ambient temperature +40°C PUMP MOTOR AISI/304 shaft and impellers Motor with copper winding Max. liquid temperature 60°C Built-in thermal protector for single phase motor Max. inlet pressure 10 bar Insulation class F Max. operation pressure 10 bar Protection class IPX4 Liquid pH valvue 6.5 - 8.5 Max. ambient temperature +40°C HORIZONTAL BOOSTER PUMP • Stainless steel horizontal multistage pump • Power: 0,37 kW/230V - 4 kW/400 • Max. volume: 3,6 m3/h - 28 m3/h • Max. height: 16 m - 55 m • Available in full stainless steel AISI/304 (ECHS) ECH2 - ECH20 HORIZONTAL BOOSTER PUMP • Stainless steel horizontal multistage pump • Power: 0,37 kW/230V - 4 kW/400V • Max. volume: 3,6 m3/h - 28 m3/h • Max. height: 16 m - 55 m • Available in full stainless steel AISI/304 (ECHS) EDH(m)2 - EDH4 - EDH15 BOOSTER PUMPS stainless steel horizontal multistage pump
10 ENGINE PUMPS medium pressure - high pressure - diesel ACCESOIRES / SPECIALS MEMBRANE TANKS • Coated or SS-AISI/304 • Membrane: EPDM • Actual capacity: 18 ltr- 100 ltr • Max. temperature: 99°C • Max. pressure: 8 bar • Connection: G1” 19CT - 24CT - 50CT - 100CT ELECTROMAGNETIC SWITCH • Rated voltage: 220V-240V/110V - 120V - 50/60 Hz • Max. power: 1,1 kW/1,5kW - 10A - IP55 • Starting pressure setting: 1,2/1,5/2,2 bar • Connection thread: G1” • Max. operation temperature: 60°C PS-04A GASOLINE 4 STROKE ENGINE • Power LGP 20H/LGP20-2H: 6,5kW • Max. volume LGP 20H: 30 m3/h • Max. volume LGP 20H-2H: 20 m3/h • Max. height LGP 20H:58 m • Max. height LGP 20-2H: 81 m • Max. suction: 5 mm/120s • Inlet: 50 mm • Outlet: 38 mm/1 x 38 mm + 2 x 25 mm • Rated speed: 3600 rpm LGP20H - LGP20-2H GASOLINE 4 STROKE ENGINE • Power LGP 15A until LGP 30A: 1,6 kW until 6,5 kW • Max. volume: 2 m3/h - 60 m3/h • Max. height: 38 m - 32 m • Inlet/outlet: 25 mm/ 38 mm/50 mm/80 mm LGP20-A / LGP30-A LGP20-A-1 / LGP30-A-1 PUMP MOTOR Anti-rust cast iron impeller Single cylinder Anti-rust cast iron diffuser Air-cooled To transfer clean water with liquid temperature between 0°C and 40°C. Applicable in water supply and drainage for factories, mines, municipals facilities as well as field irrigation, etc.
For more product information, technical data and product manuals, visit our website www.leopumps-europe.com. 11 CONTACT HEADQUARTER / BELGIUM LEO Baekelandlaan 5209 3900 Pelt +32 11 64 91 94 contact@leopumps-europe.com EUROPE PARTNERSHIP NETWORK & GERMANY Gerhard Klier Head of Sales +49 17 11 17 32 28 gklier@leopumps-europe.com Martin Barmeier Country Manager Germany +49 176 34 36 23 99 martin@waterislifegroup.com PARTNERSHIP NETWORK & AUSTRIA Christian Helminger Area Sales Manager +43 66 04 77 39 00 chelminger@leopumps-europe.com PARTNERSHIP NETWORK & SPAIN Veronique Van Simay Area Sales Manager +39 34 21 25 43 44 veronique@leopumps-europe.com GLOBAL PARTNERSHIP NETWORK Raf Corten General Manager +32 11 64 91 94 info@leopumps-europe.com PARTNERSHIP NETWORK & FRANCE Veronique Van Simay Area Sales Manager +39 34 21 25 43 44 veronique@leopumps-europe.com Gérald Achard Account manager +33 6 25 04 25 11 gerald@waterislifegroup.com PARTNERSHIP NETWORK & ITALY Veronique Van Simay Area Sales Manager +39 34 21 25 43 44 veronique@leopumps-europe.com
12 LEO PUMPS EUROPE BV Leo Baekelandlaan 5209, 3900 Pelt, Belgium Tel.: 0032(0)11/64 91 94 E-mail: contact@leopumps-europe.com Central European product availability Warranty of 24 months Showroom Standardization Program European warehouse As one of the worldwide leaders in the engineering and manufacturing of waterpumps, the time was right for LEO pumps to establish an European Office and warehouse in Europe. Started up in 2017 and located in the north east of Belgium, the new European Headquarter in the centre of Europe was born. Our goal is to have the LEO products available in all European countries, with short delivery times by our own delivery service. With its right quality labels and professional trend-setting design and packaging, Leo Europe has the aim to be the number one European supplier for all range of waterpumps. Together with our great team with more than 30 years of experience in the waterpump market, and our own in-house service and repair centre, we can assist all of our distributors in a very short time. With its unique designs, high performances and European standards, LEO Pumps is aiming to become a leading pumpsupplier in this high-end EU-market. All the pumps are covered by 24 months full warranty. In order to ensure a higher availability of our products, we have opened a brand new European logistics centre in the middle of Europe where we can give direct customer support in your preferred language. We have also created our SSP (Showroom Standardization Program) to support your sales efforts in the best possible way. Feel free to ask how LEO can boost your pump-business. About Leo Europe WWW.LEOPUMPS-EUROPE.COM INTELLIGENT FLOW FOR GOOD 24MONTHS WARRANTY★WARRANTY★WARRANTY★ Water is life, we take care of it.
